| Place of Origin: | China |
| Brand Name: | VALUES GLASS |
| Certification: | Upon Request |
| Model Number: | Smart Glass |
| Minimum Order Quantity: | 5 pieces |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood Pallet or per request |
| Delivery Time: | 14 Days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 10,000 sq.meter/Month |
| Product: | Switchable Smart Glass | Shape: | Flat, Curved |
|---|---|---|---|
| Material: | Clear Glass | Application: | Windows, Door, Office, Bank, Hotel, Hospital |
| Film Color: | Clear, Milky, Grey, Blue, Green, Red | Thickness: | 5+5mm, 6+6mm, Etc |
| Size: | Customized | Function: | Privacy, Safety |
| Highlight: | Laminated Switchable Smart Glass,39dB Switchable Smart Glass,39dB Smart Tint Glass |
||
Large Size Laminated Switchable Smart Glass Used for Privacy Protection
What's the function of Switchable Smart Glass / Privacy Glass:
(1) Privacy partition: The biggest function of smart glass is the privacy protection function, which can control the transparent and opaque state of the glass at any time, and have a strong spatial extension effect, privacy, openness, and freedom
(2) Safety and explosion-proof: The middle-layer smart film can tightly absorb glass fragments when the glass is hit by high intensity, effectively preventing glass splashing and hurting people.
(3) Projection: Smart glass is still this very excellent projection hard screen. In a suitable light environment, if you choose a high-lumen projector, the projection imaging effect is very clear and outstanding. (Recommended to use rear projection imaging method)
(4) Heat insulation and sun protection: The smart film in the middle of the dimming glass can insulate and block more than 99% of ultraviolet rays and 98% of infrared rays. Shield some infrared rays to reduce heat radiation and transmission. And shielding ultraviolet rays can protect indoor furnishings from fading and aging due to ultraviolet radiation, and protect personnel from diseases caused by direct ultraviolet rays.
(5) Sound insulation and noise reduction: The smart film in the middle of the glass has a blocking effect on noise, and the anti-noise ability is increased by more than 20% compared with ordinary glass.
What is Switchable Smart Glass:
Switchable Smart glass (also called switchable glass, intelligent glass, privacy glass or magic glass ) is a kind of high-tech product can switch from transparent to opaque instantaneously. It is transparent when power on and it is opaque when power off, light transmission properties can be changed when voltage is applied.
The glass is composed of toughened glass and smart film which form a sandwich like structure. The usage of smart glass can provide a more privacy and safety room.
| Parameters | Thickness:390±10 um | |
| Voltage: 60V | ||
| Power: <10W/M2 | ||
| Parallel luminous transmittance(electricity off):<6 | ||
| Parallel luminous transmittance(electricity on):<65 | ||
| stickness: 200 | ||
| Voltage Tolerance: no breaking point, | ||
| Optics | Visible transmittance | Electricity On:>75% |
| Electricity Off<1% | ||
| Haze | Electricity On:<7% | |
| Electricity Off>90% | ||
| Viewing angle | Electricity On:about 140degree | |
| UV shielding | Electricity On:>99% | |
| Electricity Off>99% | ||
| Shielding infrared | Electricity On:>30% | |
| Electricity Off>90% | ||
| Elecrical | Operation Voltage | Electricity on: 40V/48V/65VAC |
| Response Time (in room) | Electricity Off-On: <200ms | |
| Electricity On-Off: >10ms | ||
| Power | Electricity On: 6W/M2 | |
| Physics | Size | Thickness:0.55mm |
| Max size: 1800*3500mm | ||
| Ambient | Operation Temp(On-Off):-30˚C-80˚C | |
| Storage Temp(On-Off):-40˚C-90˚C | ||
| Life | More than 10years | |
| Sound | STC 6+6 Tempered Glass: 39dB | |
| Switch Times | >100,000 times | |
Application of Switchable Smart Glass:
Other Products we offer:
-- Tempered glass;
-- Insulated glass;
-- Laminated glass;
-- Smart glass & self-adhesive PDLC film;
-- Non-reflective glass panels, anti-glare glass panels;
-- Vacuum glass;
-- Stained / fused glass;
-- LED glass, LED mirror;
Our advantage:
Why choose us:
| Item | state | Smart film | Smart glass | ||
| Optical Properties | Visible Light Transmission | ON | ≥80% | ≥78% | |
| OFF | ≤5% | ≤52% | |||
| Parallel Light Transmission | ON | ≥79% | |||
| OFF | ≤5% | ||||
| Visual Angle | ON | 150 | 120 | ||
| UV Blocking | ON/OFF | ≥99% | |||
| Haze | ON | ≤5% | |||
| OFF | ≤92% | ||||
| Heat Resistance | R/RO | 0.8-1.1 | |||
| Electrical Properties | Operating Voltage | ON | AC60V or AC40V | ||
| Power Consumption | ON | 12.5W/m² | |||
| AC.Transformer | / | 50W,100W,200W,300W/SET | |||
| Specification | Thickness | / | 0.38mm | 9-24mm | |
| Max Width | / | Self-adhesive | Non-adhesive or glass | ||
| / | 1500mm | 1580mm | |||
| Color | / | White,dark gray,light gray,blue,green,pink,red | |||
| Life time | / | More than 50000hrs | |||
| Working Temperature | / | / | -20-60°C | ||
