Low Reflectivity Anti Reflective Glass , AR Anti Reflective Glass Cut To Size

Low Reflectivity Anti Reflective Glass , AR Anti Reflective Glass Cut To Size

  • Low Reflectivity Anti Reflective Glass , AR Anti Reflective Glass Cut To Size
Low Reflectivity Anti Reflective Glass , AR Anti Reflective Glass Cut To Size
Product Details:
Place of Origin: China
Brand Name: VALUES GLASS
Certification: Upon Request
Model Number: AR Glass
Payment & Shipping Terms:
Minimum Order Quantity: 5 pieces
Price: Negotiable
Packaging Details: Plywood Pallet or per request
Delivery Time: 14 Days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 5,000 sq.meter/Month
Contact Now
Detailed Product Description
Glass: Low Iron Glass Thickness: 1.1 ~ 6.0mm
Size: Max:1600*2800 Mm, Min:200*200mm Light Transmittance: Visible Light Transmittance >=94%
Scratch Resistance: >=8H Application AR Glass: Electronic Display, Museum Showcase, Picture Frame,
Highlight:

anti reflective glass cut to size

,

uv resistant glass

Product Description:



Anti-reflective glass (AR glass) is also called high transmittance and low reflectivity glass, add-transmissivity glass which is manufactured through coating two to multiple transparent anti-reflection layers on single or double sides of glass by advanced vacuum coating technology.

Product Name 2mm 3mm Anti Reflective Glass AR Glass Single Side Coated Anti Reflection Glass
Raw Material Low Iron Glass
Thickness 1.1 ~ 6.0mm
Thickness tolerance

±0.2mm

Max dimension 1,600 * 2,800mm
Min dimension 200 * 200mm
Light Transmittance

Visible Light Transmittance >=94%

Reflectivity <=5%

Application Electronic Display, Museum Showcase, Picture Frame, Lighting, Cold Storage.







Anti-Reflective glass(AR) is also called add-transmissivity glass.



Adopting advanced magnetron sputtering vacuum coating technology, to coat the Nano optics multilayer film on the glass surface, it can enhance the transmissivity of glass from 89% to >=96%, and decrease reflectivity from 8% to <=2%.



If four layers AR film coated on double surfaces, the transmissivity can be >=98%, the reflectivity can be <=1%, no reflect and anti giddy light, it makes image more clear against strong light and improves the screen brightness to protect eyes.







Remark:

1. This AR glass is to meet customer need under wavelengths of visible light.

2. Light transmittance under different wavelength can be adjusted to meet diversitied need.









Low Reflectivity Anti Reflective Glass , AR Anti Reflective Glass Cut To Size 0









Low Reflectivity Anti Reflective Glass , AR Anti Reflective Glass Cut To Size 1
